Item | Description | ||
Motion(5-Axis) | X-1/X-2Axis | Stroke1300mm |
Accuracy:± 20um Velocity:Max.1,000mm/sec Z-ServoMotorHomePosition功能 |
Y-Axis | Stroke500mm | ||
Z-1/Z-2Axis | Stroke110mm | ||
CONVEYOR |
Width 250~400mm (可对应100mm以内 /±20mm) |
大约 LENTH2000mm | SPEED:5~100m/min |
Vision / Camera |
Controller | Cognex PCIFrameGrabber | |
Cognex GeometricLICKey | |||
CCDCamera | SonyXX– XX50(UVCamera) | Resolution:0.012mm/pixel | |
Light/Controller | 4Ch. | 各 2ch | |
Utility | Power | 220VAC,50~60Hz | |
AirPress | 0.4~0.5MPa | ||
Size | . | ||
Option | 2DBCR,各产品的安装 Jig. |
